Horizontal Flow Pillow Bag Packaging Machine With Fast Photoelectric Track

Product Categories

Shanghai Yanban Machinery Co., Ltd.

Contact Now

Place of Origin : Shanghai, China (Mainland)

Brand Name : YB

Model Number : YB-350X

Certification : CE

Price : US $5,300-5,450 / Sets | 1 Set/Sets flow pack packaging machine (Min. Order)

MOQ : 1 Set/Sets

Payment Terms : L/C, T/T, Western Union

Supply Ability : 25 sets per month

Delivery Time : 20 working days

Packaging Details : wooden box

Product name : Horizontal Flow Packing Machine

film width : 90-350(mm)

warranty : 1 year

power : 220V

machine size : L4000*W950*H1500mm

net weight : 500kg

screen : color touch screen

controller : PLC

Contact Now

Candied fruit sticky candy Down-paper automatic pillow packing machine

Product Description

Usage

This machine is mainly used for packaging irregular/soft/a little sticky products, such as sweetmeat, soft candy, cake, wet towel,

non-woven, tableware, plasticine, absorbent cotton, shower cap, toy, hardware, etc.

Function and Features

1. Color touch screen display, PLC/computer control, automatic and fast photoelectric track.

2. The bag length need not be set, machine could detect it automatically.

3. Machine has high performance, simple operation and fast packing speed.

4. Gear system besides double frequency converter controller, which making machine simpler operation, high-speed and

stable performance. It’s the first third-generation pillow type packing machine in China.

Technical Parameter

Model	YB-350X
Packing speed	35-180 bags/min
Width of film	90-350 mm
Making bag size	(Double low cutter) L 65-190, W 30-160, H 5-50 (mm) (Double high cutter) L 90-220, W 30-160, H 5-60 (mm) (Single high cutter) L 150-330, W 30-160, H 5-60 (mm)
Total power	2.4 KW
Power supply	1 Ph. AC220V, 50/60Hz
Machine size	L4000 × W950 × H1500mm
Net weight	500kg

Horizontal Flow Pillow Bag Packaging Machine With Fast Photoelectric Track

pillow packing machine
